Type

2 Ports In- 1Port Out

Port

Port 1

Port 2

Operating Frequency

Band1

698~960 MHz

1710~1880 MHz

Band2

698~960 MHz

1920~2170 MHz

Band3

800~960 MHz

1710~1880 MHz

Band4

800~960 MHz

1710~2170 MHz

Band5

800~960 MHz

1920~2170 MHz

Band6

800~960 MHz

2400~2700 MHz

Insertion Loss

≤0.3 dB@band1&2&3&4&5  ≤0.5 dB@band6

In-band Ripple

≤0.2 dB@band1&2&3&4&5  ≤0.3 dB@band6

VSWR

≤ 1.22

Rejection

≥80.0 dB

Inter-modulation (3rd order)(Customized)

≤-140 dBc(@ 2 x 20 W)

Power Handling

200W

Connector Type

N female

Application

Indoor

MTBF

10 Million Hours

Impedance

50 Ω

Operating Temperature (°C)

-25°C to +65°C

Relative humidity

5% - 95%

Wight

1.3Kg
