Type

4 Ports In- 1Port Out

Port

Port 1

Port 2

Port 3

Port 3

Operating Frequency

Band1

800~960 MHz

1710~1880 MHz

1920~2170 MHz

2330~2400 MHz

Band2

800~960 MHz

1710~1880 MHz

1920~2170 MHz

2500~2700 MHz

VSWR

< 1.3

Insertion Loss

<0.4 dB@( 800 – 960 MHz)

<0.4 dB@(1710 – 1880 MHz)

<0.4 dB@(1920 – 2170 MHz)

<0.4 dB@(2330 – 2400 MHz)/(2500~2700 MHz)

Isolation Between Bands

>50.0 dB

Inter-modulation (3rd order)

<-140dBc(@ 2 x 20 W

Power Handling (W)

200W

Connector Type

N female

Application

Indoor

MTBF

10 Million Hours

Impedance

50 Ω

Operating Temperature (°C)

-40 °C to +65 °C

Wight

2.4Kg
