Model

AT22050627DF

AT22060627DF

AT22070627DF

AT22080627DF

AT22100627DF

AT22130627DF

AT22150627DF

AT22200627DF

Frequency Range

698-1400&1700-2700MHz

Output Split Ratio

2:1/3dB

3:1/4.8dB

4:1/6dB

6:1/8dB

10:1/10dB

20:1/13dB

30:1/15dB

100:1/20dB

Dissipation Loss

≤0.25dB(Main Line)

Main/Branch

-1.8dB/-4.8dB

-1.3dB/6.1dB

-1dB/-7dB

-0.6dB/-8.6dB

-0.4dB/-10.4dB

-0.2dB/-13.2dB

-0.1dB/-15.1dB

-0.1dB/-20.1dB

Branch Flatness

±1.2

±1

±0.8

±0.8

±0.8

±0.8

±0.8

±0.8

PIM3

≤-150 dBc@2×43dBm

VSWR

≤1.3

Impedance

50Ω

Power Rating

300 W(Avg.)

Operating Temperature

-35°C to +75°C

Relative Humidity

5% - 95%

Application

Indoor or Outdoor(IP65)

Connectors Type

DIN –Female

Weight

250g

Dimensions

105*25*25mm(without connector)

Packing

1 Pce/box
